Sterile Air Filter Housings
Click to Download the Housing Table:
- Sterile Air Filter Housings (581.51 KB)
Download the Domnick microBAN Housing Table
| Filter Model | Pipe Size | Flow Rate | Dimensions (inches) | Dimensions (mm) | Weight | Cartridge Model | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SCFM | dm³/s | A | B | C | D | A | B | C | D | lbs | kg | |||
| MRF1*-MBN | 1/8" | 3.0 | 1.5 | 3.7 | 2.2 | 0.5 | 1.0 | 94.0 | 56.0 | 12.0 | 2.4 | 2.2 | 1.0 | MER1SRL-MBN |
| MRF2*-MBN | 3/8" | 8.0 | 4.0 | 4.4 | 3.4 | 1.1 | 3.4 | 112.0 | 86.0 | 28.0 | 86.0 | 2.2 | 1.0 | MER2SRS-MBN |
| MRF3*-MBN | 3/8" | 12.0 | 6.0 | 6.3 | 3.4 | 1.1 | 3.4 | 160.0 | 86.0 | 28.0 | 86.0 | 2.6 | 1.2 | MER3SRS-MBN |
| MRF4*-MBN | 1" | 35.0 | 17.0 | 6.5 | 4.0 | 1.6 | 5.0 | 165.0 | 102.0 | 41.0 | 127.0 | 6.2 | 2.8 | MER3SRS-MBN |
| MRF8*-MBN | 1" | 70.0 | 33.0 | 10.5 | 4.0 | 1.6 | 5.0 | 267.0 | 102.0 | 41.0 | 127.0 | 8.8 | 4.0 | MER8SRL-MBN |
| MRF12*-MBN | 1" | 100.0 | 48.0 | 14.5 | 4.0 | 1.6 | 5.0 | 368.0 | 102.0 | 41.0 | 127.0 | 11.0 | 5.0 | MER12SRL-MBN |
| MRF15*-MBN | 1 1/2" | 120.0 | 57.0 | 19.1 | 8.3 | 3.6 | / | 486.0 | 210.0 | 92.0 | / | 11.0 | 5.0 | C12MERBSRL-MBN |
| MRF24*-MBN | 1" | 175.0 | 83.0 | 27.4 | 4.0 | 1.6 | 5.0 | 695.0 | 102.0 | 41.0 | 127.0 | 15.5 | 7.0 | MER24SRL-MBN |
| MRF30*-MBN | 2" | 225.0 | 107.0 | 29.8 | 8.7 | 3.6 | / | 758.0 | 220.0 | 92.0 | / | 15.5 | 7.0 | ME24BSRL-MBN |
| MRF305*-MBN | 2 1/2" | 450.0 | 214.0 | 39.0 | 11.3 | 4.5 | / | 990.0 | 287.0 | 115.0 | / | 37.5 | 17.0 | MER305BSRL-MBN |
Note: Please specify connection type when ordering . Substitute * with NPT or TC if Tri Clamp connection is required.
Drawings showing housings dimensions are available upon request.
Correction Factors
Correction factors to be applied to above flow rates at other pressures.
| Operating Pressure | barg | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| psig | 15 | 30 | 44 | 58 | 73 | 87 | 102 | 116 | 131 | 145 | |
| Correction Factor | 0.70 | 1 | 1.22 | 1.41 | 1.58 | 1.73 | 1.87 | 2.00 | 2.12 | 2.24 | |
